HIMOD系列旗艦型是公司1999年初開發出新型節能及模塊式HIMOD系列溫恒濕空調和MICROFACE控制器，它們不但保留了HIRANGE系列的優點，同時又增加了很多新的高技術成果。HIMOD系列產品于1999年后期在中國和歐洲同時開始銷售，受到新、老客戶的贊譽。
HIMOD flagship series was developed by the company in early 1999 including the new type of energy saving and modular HIMOD series of temperature and constant humidity air conditioning and MICROFACE controller. It retains the advantages of HIRANGE series, and also increases a lot of new high technology achievements. The HIMOD series products in late 1999 in China and Europe also began selling, by the new and old customers praise.
HIMOD系列旗艦型機組的設計
HIMOD系列旗艦型采用真正的模塊化設計思路。HIMOD的基本模塊從20KW到40KW制冷量，分為五個型號有8種制冷系統。與其他廠家的模塊化設計的不同點是，HIMOD系列產品可以根據用戶的需要將不同冷量的模塊組合成一個制冷系統，每個系統可容納的最多模塊數為16個。在一個系統的每個模塊中都有獨立的控制器MICROFACE。用戶可以在MICROFACE上設定每個模塊的工作參數。
Design of HIMOD flagship series
HIMOD flagship series is used the modular design. The cooling capacity for the basic module of HIMOD flagship series is from 20kW to 40KW. It divides into five models that have 8 kinds of refrigeration system. Different from other manufacturers, HIMOD series product can be combination of modules according to the needs of users of different cooling capacity. Each system can accommodate the most module number of 16. Each module of a system has its own MICROFACE controller. The user can set the parameters of each module through the MICROFACE.
生產的單制冷回路和雙制冷回路HIMOD系列旗艦型系列精密空調，可以提供單機的制冷量為20KW至103KW，并可組合在一起。即能滿足現階段的使用，又能適應未來發展的需求，具有非常廣泛的應用范圍。它采用了先進的微處理器控制技術，完全滿足機房對環境的精密控制要求。并且機組控制器可完成各機組間的定時切換及故障切換，同時便于空調系統的集中管理。HIMOD系列旗艦型的加濕系統是可拆式電極罐式加濕器。
Single cooling loop and double cooling loop HIMOD flagship series of precision air conditioning, the refrigeration capacity is from 20KW to 103KW for a single unit which can be combined together. It can satisfy the use at the present stage and can adapt to the needs of future development with a very wide range of applications. It uses an advanced microprocessor control technology that fully meets the requirements for the environment of precision control in the computer room. A controller can complete the timing switching and fault switching for units. It also centralizes the management which is convenient for air conditioning system. Humidification system of HIMOD flagship series is detachable electrode tank type humidifier.
為了適應許多水質很差的地區使用，它采用了獨特的控制技術并使用了“模糊邏輯”控制軟件。它可以根據水的電導率，自動調整電極的電流值。同時，它可以根據水的硬度，確定加濕罐的沖洗次數。加濕器為可拆裝式，對加濕器進行清洗后可繼續使用，一方面，可以延長加濕罐的使用壽命；另一方面，可以使加濕器達到最高的使用效率。因此，它可以用在水的電導率特別高的環境——常常是在很偏遠的地區。
In order to adapt many areas of poor water quality, it adopts the control technology which is unique and the use of "fuzzy logic" control software. It can be based on the conductivity of the water current and automatically adjust the value of the electrode. At the same time, it can be determined according to the hardness of water and flushing times for the humidification tank. The humidifier is removable. To clean the humidifier can be continued to use, on the one hand, can prolong the service life of tank. On the other hand, it can make the humidifier that has the highest efficiency. Therefore, it can be used in the electrical conductivity of water that is particularly high environment -- often in remote areas.
HIMOD系列旗艦型采用了交互“V型”盤管，采用了帶內螺紋的銅管及沖縫型翅片，比采用傳統式盤管的機組有更高的傳熱效率。采用“V型”結構盤管可使制冷系統的循環與制冷負荷相匹配，并且通過盤管表面的氣流更加平穩，最大限度的降低機組噪聲。
HIMOD flagship series uses interactive "type V" coil, the internal thread copper tube and punched slotted fin, and heat transfer efficiency is higher than the traditional coil unit. The "V" structure of coil can make refrigeration system cycle match the refrigeration load, the gas flow through the coil surface is smooth, and the "V" structure of coil also reduces the noise.
因此我們可以看到HIMOD系列旗艦型的設計思路，不僅僅考慮了現在，而是為了將來，具體特點如下：
So we can see the design idea of HIMOD flagship series, consider not just now, but in the future, specific features are as follows:
1.先進的微處理控制器：
HIMOD 系列旗艦型的微處理控制器配有帶背景燈的MICROFACELCD顯示器，正常情況下，可以顯示回風的濕度和濕度及機組的序列號，設定點的溫度和相對濕度，和工作狀態顯示(制冷、加熱、加濕、去濕)，風機狀態以及各種報警。Hiromatic圖形控制器圖形顯示最近48小時內的溫度和相對濕度的曲線，友好的用戶操作菜單界面可以使操作人員很方便的對系統和報警狀態進行查詢及消聲，例如：高溫、低溫、高濕、低濕、氣流丟失、更換過濾器、壓縮機超高壓報警等等。具備多級密碼保護功能，包括設定點的改變、報警閥值的設定、通訊的設置及機組的設置等項目都可以通過密碼保護。內置的電源節省功能可以在輸入電源低于允許的設定電壓范圍時自動關閉機組。安裝在控制板上的備份電池可以當主電源出故障時，保存機組的設定參數和歷史記錄。模塊化HIMOD 系列旗艦型的每個模塊都有獨立的內部控制器，并且可以根據現場情況，將各模塊通過備選組件連接。當某一模塊出現報警時，自動啟動備用模塊，并且可以使模塊循環工作，平衡各模塊的使用時間。Hiromatic圖形控制器通過RS232接口可以連接和PC機，可以監控到機組的所有數據。如采用了遠程的PC機及調制解調器后可實現機組的遠程監控。開放通訊軟件方便的與主要的(BAS)樓宇自動控制系統相連接，例如：JOHNSON，HONEYWELL 等。
1. Advanced micro processing controller:
The Micro processing controller of HIMOD flagship series is equipped with MICROFACELCD display with backlight under normal circumstances that can display the sequence number of moisture and humidity, the set point temperature and relative humidity, the working state display (refrigeration, heating, humidification, and dehumidification), fan status, and alarm. Hiromatic graphics controller displays the last 48 hours of temperature and relative humidity curve. The user-friendly menu allows the operator to easily query the state of the system. For example: high temperature, low temperature, high humidity, low humidity, air flow loss, replacing the filter, compressor high pressure alarm etc. Multilevel password protection function includes the set point changes, the alarm threshold settings, communication settings, and unit setting items. Built in power saving function is allowed automatic closing unit when the input power is reached the range of setting voltage. Backup battery installed in the control board recording the parameters of units prevents when the main power supply is failure. Each module of the modular HIMOD flagship series has internal controller independently, and according to the environmental conditions, each module is connected by the alternate component. When a module has alarm, the controller automatic starts standby module. The controller can also balance the cycle time of module. Hiromatic graphics controller can be connected with PC through the RS232 interface for monitoring all data sets. By using the PC on site and the modulator can realize the remote monitoring for the unit. Open communication software is convenient for connecting to the building’s control system, for example: JOHNSON, HONEYWELL, and etc.
2.可維護性：
HIMOD 系列旗艦型的所有日常維護工作都可以在機組的正面完成，所有的部件都可以從機組的正面取出來。HIMOD 系列旗艦型模塊的空氣過濾器可以從機組的正面進行更換。在機組正常運行的情況下，可以對制冷系統進行檢修。
2. Maintenance:
All the routine maintenance work of HIMOD flagship series can be accessed in front and all parts can be taken out easily. Air filter can also be replaced in front. Under the normal operation condition, the maintenance of the refrigeration system can be carried out.
多種冷卻方式：由于HIMOD 系列旗艦型非常靈活的設計，使其可以采用多種冷卻方式。
Various cooling methods: Because the design of HIMOD flagship series is very flexible, it can be utilized in a variety of ways of cooling.
3.氣冷卻系統：
為了保證整個系統工作的可靠及高效，需根據室外環境溫度匹配合適的空氣冷凝器。為了防止在運輸過程中潮氣及雜物的侵入，機組已經在出廠前預先充注了干燥的氮?dú)?。在安裝機組時需注意機組的氣管和液管，要根據冷凝器的安裝距離，選擇規格合適且符合制冷要求的銅管。
3. Air cooling system:
In order to ensure the whole system is reliable and efficient, the suitable air condenser is used according to the environment temperature of outdoor. In order to prevent the intrusion of moisture and impurities in the transport process, the unit has been in the factory pre filled with dry nitrogen. In the installation of unit should pay attention to set pipe and the liquid pipe, according to the distance of the condenser, choose suitable specification and in accordance with the requirements of copper tube.
HIMOD 系列旗艦型優勢
Advantage of HIMOD flagship series
1.安裝方式靈活多樣，適合各種場合。模塊化設計適應特殊場地搬運，可在現場專業拆裝，以便通過狹窄的樓梯、樓道、電梯。
1. Flexible installation is suitable for all occasions. Modular design adapts to the special ground handling, can be applied in the field of professional disassembly, and it can go through the narrow stairs, corridor, and elevator.
2.高品質、低能耗的谷輪柔性渦漩式壓縮機。防液擊，高能效比。
2. Copeland flexible vortex type compressor has low energy consumption, high quality, liquid strike prevention, and high energy efficiency ratio.
3.超大表面積的蒸發器盤管。提高機組效率確保節能。采用“V型”結構盤管可使制冷系統的循環與制冷負荷相匹配，并且通過盤管表面的氣流更加平穩，最大限度的降低機組噪聲。除濕時，關掉部分盤管，只利用2/3的部分盤管，將65%的能量用于除濕，能更有效地去掉濕氣，大大減少再熱器的啟動，節能效果顯著。
3. The large surface area of the evaporator coil improves the efficiency of generating units to ensure the energy saving. The "V" structure of coil can make refrigeration system cycle match the refrigeration load, the gas flow through the coil surface is smooth, and the "V" structure of coil also reduces the noise. When dehumidification, turn off the coil that only uses the part of 2/3. 65% of energy is used for dehumidification and it can effectively remove the moisture, greatly reduce the heater restarting, and obviously provide energy saving effect.
4.低噪聲。壓縮機安裝在橡皮膠避震底座上，減少噪音和震動。并將其設計在氣流之外。氣流通道曲線設計，減少噪音。
4. Low noise. The compressor is mounted on the rubber shock absorber base that reduces noise and vibration. And its design is in the outside of the air stream. Flow channel is the curvature design that reduces the noise.
5.三級密碼，防止非有關人員使用操作。比如，微分與積分精密控制運算?？刂茀?shù)可以個別設定以適應特殊用途。保持最近48小時內溫度，濕度記錄，每隔一分鐘測量值顯示更新一次。主要部件運行計時，如壓縮機、加熱器、加濕器及風機?？梢杂涗浂噙_(dá)100個過去的報警，并展示報警內容，編號，類型，日期，時間及延續的時間等。
5. Three stages of password prevent the non relevant personnel operation. For example, differential and integral precision control operation. The control parameters can be set individually in order to adapt to the special purpose. Keep the recent temperature and humidity records within 48 hours. Measurements are updated and displayed every minute. The main components, such as compressor heater, humidifier and air blower will recode the running time. You can record up to 100 previous alarms, and display the alarm content, number, type, date, time and duration etc.
6.HIMOD 系列旗艦型的冷凍水機組 HIMOD 系列旗艦型模塊化機組與自然冷卻系統配合使用，會有顯著的節能效果。
6. With the use of frozen water units, modular units and natural cooling system for HIMOD flagship series will have the obvious effect for the energy saving.
7.熱氣旁通：
分別安裝于各個制冷回路中，精調制冷系統，使機組的制冷量與機房的需要匹配完善。因此可以減少壓縮機的頻繁啟動。
7. Hot air bypass:
Hot air bypass channel is respectively arranged in each refrigeration circuit and fine adjustment of refrigeration system that makes the cooling capacity and the need of room unit matching perfect, so it can reduce the compressor frequent starting.
8.地板支架：
高度可調整的地板支架，可以使HIMOD 系列旗艦型模塊機組與機房的活動地板成為一體。
8. The floor bracket:
The floor bracket height is adjustable. To make the HIMOD flagship series module unit and engine room floor activities becomes one.
9.多種風帽：
根據機房現場的情況，HIMOD 系列旗艦型室內機組可匹配不同的風帽在下送風機組中，可安裝回風風管道與機組相連接。在上送風系統中，上送風風帽可使機房各個角落的氣流穩定均勻。
9. A variety of cap:
According to the room situation, HIMOD flagship series indoor unit can be matched with different air blower unit, and can be installed air duct that is connected with the unit. For upper air supply system, upper air flow hood can make every corner room which is stable and uniform.
10.煙感探測器：
當感測到煙霧時，立即關閉主風機，同時發出報警聲。
10. Smoke detector:
When the sensor detects the smoke, the unit is closed the fan immediately, and issued a warning sound.
11.冷凍水系統的選件：
包括水流開關，旁通管上的平衡閥，彈簧式冷凍水回水閥，耐高水壓（24bar）的冷凝器組件等。
11. The frozen water system:
The frozen water system includes the flow switch, balance valve on the bypass pipe, spring type frozen water return valve, and high pressure (24bar) of the condenser components.
12.火災報警器：
是非常靈敏的感熱開關當它探測到機內過熱或出現火種時立即關閉主風機。
12. Fire alarm:
The fire alarm system is equipped with the heat sensitive switch when it detects that the machine overheating or fire appears immediately shut down the main fan.
13.遠程溫、濕度傳感器：
一般的傳感器都是安裝在機組的內部探測回氣的溫、濕度。選擇遠程溫、濕度傳感器，就可以安裝在地板下或需要的空間中，可以更準確的控制溫濕度的變化。
13. Remote temperature and humidity sensor:
The temperature and humidity sensor is general installed inside the unit. Selecting the remote temperature and humidity sensor, you can install it under the floor or in the needed space that can control the temperature and humidity change accurately.
14.冷凝水泵：
這是一個將水箱、馬達、泵及其輔件和自動控制部件合成一體的組件。它可以將加濕器排水及冷凝水排水輸送到適當?shù)牡胤健?/span>
14. Condensate pump:
This combines a water tank, motor, pump and its accessories and automatic control parts into the integrated component. It can convey the humidifier drainage and condensed water drainage to the proper place.
15.點式或區域型漏水報警器：
HIROSS點式和區域型漏水報警器能夠指示出現漏水的具體位置及在某些敏感地區出現的潮氣。
15. The point or area Water Leakage alarm:
The point type and regional type Water Leakage alarm can indicate the position of Water Leakage and moisture in certain sensitive areas.
16.加熱器/加濕器的緊急電源切斷裝置：
這個選件可以在接到外部的24V信號后，經過必要的延時后，停止加熱器及加濕器的工作。(例如，當機機組轉到由柴油機組供電時)。
16. Emergency power off device for heater / humidifier:
This option can top the heater and humidifier after the necessary delay with the external 24V signal. (For example, when the unit is switched to the diesel engine for power supply).
17.主風機過載：
當主風機馬達的運行電流值超過預先設定值時，就會發出報警信號。
17. Fan overloaded:
When the current value for the fan motor exceeds a preset value, the unit will send out the alarm signal.
18.壓縮機過載報警：
當制冷系統的壓縮機的運行電流值超過爭先設定值時就會發出報警信號。
18. The compressor overloaded alarm:
When the current value of compressor for the refrigeration system exceeds a preset value, the unit will send out alarm signal.
19.遠程監控面板
可安裝在主機之外的遠程監控面板能完成機組上主控制板的顯示及所有控制功能。
19. Remote control panel
It can be installed to the main control panel outside the unit which can display all control functions.
20.綠色制冷劑：
公司非常重視環境保護的問題?，F(xiàn)在，HIMOD 系列旗艦型標準型機組選用的是R22制冷劑，這是HCFC類制冷劑，其臭氧破壞指數（ODP）值非常低。此外，HIMOD 系列旗艦型也可以選用R407C制冷劑——現在已經廣泛地得到應用。在歐洲，公元2000年以后生產的新制冷設備中，將不再采用R22制冷劑，采用新型制冷劑的空調系統，可以提供與采用R22制冷劑相同的制冷功率。需注意的情況是，選用新型制冷劑的壓縮系統，需使用合成酯類潤滑劑替代礦物質油。
20. Green refrigerant:
The company attaches great importance to environmental protection issues. Now, the HIMOD flagship series is used the refrigerant of R22 that is HCFC kind of refrigerant and the ozone damage index (ODP) value is very low. In addition, the HIMOD flagship series can also use R407C refrigerant -- now has been widely applied. In Europe, the new refrigeration equipment will not use R22 refrigerant after 2000. The air-conditioning system using new refrigerant can provide the same effect as R22 refrigerant. Need to pay attention to that the compression system using new refrigerant needs to replace the mineral oil with synthetic ester lubricant.
HIMOD系列旗艦型系列機組是為滿足各種計算機及交換機房特殊要求而設計的完善的機房專用空調系統，是用途廣泛的精密空調系統。
HIMOD flagship series is to meet the various computers and exchange room for special requirements. It is a precision air conditioning system widely used.
一般情況下“舒適性”空調多數是為普通的使人們感到舒適的環境而設計，不適用于諸如電子設備非常集中的環境。為什么呢？這是由于一般的“舒適性”空調沒有足夠的制冷能力和控制高濕和低濕的方法，并且會因過度去濕而使空氣過干而產生靜電，這對于精密的電子設備是一個危險的“殺手”。HIMOD 系列旗艦型系列精密空調機組，可提供連續地、精確地溫、濕度控制。這對于在計算機房、通訊機房及其它在相同的環境中工作的精密電子設備的平穩正常工作是至關重要的。因此，HIMOD 系列旗艦型被設計為提供少量“潛冷”去除潮氣，而將盡可能多的“顯冷”去除設備發出的大量的顯熱。因而可以建立滿意的機房環境，使重要的精密設備可以高效及可靠的運行。
In general the "comfort" air conditioning is mostly designed for ordinary people who feel comfortable, and not suitable for electronic equipment that is located in concentrated environment. Why? This is due to the "comfort" air conditioning that does not have enough cooling capacity and high humidity and low humidity control method. Because of the excessive moisture while the air is too dry and induces the static electricity, this is a dangerous "killer for sophisticated electronic equipment". HIMOD flagship series of precision air conditioning can provide continuous, accurate temperature, and humidity control. This is crucial for the smooth working in the computer room, communications room and precision of other electronic equipment in the same environment to work in. Therefore, HIMOD flagship series is designed to provide a small amount of "latent heat" to remove the moisture, and as much as possible to remove a lot of heat from devices. We can set up the satisfied environment to make the equipment under the efficient and reliable operation.
適合應用的范圍 Applications
計算機房和數據中心： HIMOD 系列旗艦型可以對各種從小型、中型到大型的機房或數據中心提供完善的溫、濕度控制，能夠確保在此環境運行的敏感電子設備工作的可靠性。
The computer room and data center: The HIMOD flagship series can be of various from small, medium to large room or data center to provide the temperature and humidity control and to ensure the reliability of sensitive electronic equipment working in this environment.
各種高科技環境及實驗室： 具有完善的程序控制，使機房的溫度和濕度能夠達到用戶選擇的各種設定值。
All kinds of high-tech environment and laboratory: A perfect program control makes the room that the temperature and humidity can be selected by the user settings.
標準檢測室和核準中心： 通過機組上或備選的外部顯示器的預選設定，HIMOD 系列旗艦型可以為用戶提供，在不同時刻，溫濕度設定點不同，但依然保持恒溫、恒濕的工作環境。
Standard test chamber and approval center: By pre external display unit or an alternative set, the HIMOD flagship series can be provided to the user in different time that the temperature and humidity setting point is different, but still maintain a constant temperature and humidity working environment.
備餐間： 可提供可靠的、穩定的環境和連續的溫度監測。
Pantry: It can provide reliable, stable and continuous temperature monitoring.
電信交換機房和移動機房： HIMOD 系列旗艦型具有迅速排除（電子設備）的產熱及控制機房?jī)?nèi)的濕度在穩定范圍內的能力，能提供大量的氣流以消除局部“熱點”。
Computer and mobile machinery room of telecommunication exchange: the HIMOD flagship series has quickly ruled out (Electronics) ability of the heat production and control room humidity in stable, and can provide a lot of airflow to eliminate local "hot".
工業控制室和精密加工設備： HIMOD系列旗艦型可以為這些敏感的設備提供保障防止溫、濕度的大量波動。
Industrial control room and precision machining equipment: The HIMOD flagship series can provide protection against large fluctuations in temperature and humidity for the sensitive equipment.
UPS和電池室： 由于有完善的溫、濕度控制確保了UPS工作的可靠性和延長了電池的壽命。
UPS and battery chamber: The perfect temperature and humidity control is to ensure the reliability of UPS and to prolong the service life of a battery.
醫院和檢測室： 可提供完善的環境控制。
Hospital and testing room: It can provide perfect environmental control.
|
